Pan Head Thread Cutting Metal Tapping Screws With Collar , Self Tapping Metal Screws

Name: Pan Head Thread Cutting Metal Tapping Screws With Collar Self Tapping Metal Screws
Brand: Runtai
Price: 1 USD

China Pan Head Thread Cutting Metal Tapping Screws With Collar , Self Tapping Metal Screws factory

Brand Name : Runtai

Model Number : Tapping Screws

Certification : ISO9001/TS16949

Place of Origin : Jiangsu, China (Mainland)

MOQ : 50000

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5ton/day

Delivery Time : 14-21 days

Packaging Details : Poly bag+Cartoon Box+ Wooden Pallet

Products Name : Nicekl Plated Steel Pan Head with Collar Thread Cutting Tapping Screws

Material : Stainless Steel Brass Copper Aluminum Alloy Steel

Standard : DIN,ANSI,JIS,ASTM,GB

Size : M1-M30 for choose

Surface Treatment : Zinc Plated, Nickel Plated, Zinc-Nickel Plated, Black Oxide

Grade : 4.8 8.8 10.9 12.9 for choose

Contact Now

Nicekl Plated Steel Pan Head with Collar Thread Cutting Tapping Screws

Products Description

A flange under the head distributes holding pressure and reduces the risk of crushing thin metal. They penetrate 0.025" and thinner sheet metal. Length is measured from under the flange. Head height includes the flange. hey're beveled under the head for use in countersunk holes. Screws cut threads in drilled holes as they’re turned, so they require less driving torque and cause less stress on your material than thread forming screws.

Products Specification

Material	Nickel-Plated Steel
Thread Size	6-32
Screw Size	No. 6
Screw Size Decimal Equivalent	0.138"
Length	1/2"
Flat Head Profile	Standard
Head
Diameter	0.262"
Height	0.083"
Drive Size	No. 2
Drive Style	Phillips
Drill Bit Size	No. 31
Drill Bit Size Decimal Equivalent	0.12"
Thread Direction	Right Hand
Threading	Fully Threaded
Thread Type	UNC
Thread Spacing	Coarse
Tapping Method	Thread Cutting
Tapping Screw Type	F
Head Type	Flat
Countersink Angle	82°
Tip Type	Blunt
Shank Cross Section	Round
System of Measurement	Inch
For Use In	Aluminum, Brass, Cast Iron, Sheet Metal
RoHS	Not Compliant

Note: Material, Size and Surface Treatment for choose.
